With its advanced point infrared combustible gas sensing element, the
new IR400 Combustible Gas Detector from General Monitors (USA) delivers
reliable protection against explosive hydrocarbon gases with a low power
design that installs in minutes and features heated optics to eliminate
condensation and includes a dirty optics indicator for fail safe operation.
The Model IR400 Infrared (IR) Point Gas Detector continuously monitors
combustible gases in the lower explosive limit (LEL) range and provides a 4 to 20 mA analogue signal proportional to the 0 to 100% LEL concentration. The detector also monitors other conditions such as supply voltage and optical path integrity.
The IR400 is designed to assist with operational efficiency and system problem-detection capability. The new detector, for example, uses only 4.8 W of power and with its advanced diagnostics helps to prevent unplanned plant shutdowns. Additionally, the detector requires no routine calibration, a feature that reduces demand for field technician time.
The IR400’s reliable gas detection principle of operation is based on measuring the absorption of infrared radiation passing through a volume of gas using a dual beam, single detector method. The IR detector
measures the intensity of two specific wavelengths, one at an absorption wavelength and another outside of the absorption wavelength. The gas concentration is determined by comparing these two intensities.
Configurations with analog output, Modbus and HART are available. Through the two-way digital communication protocols, users have access to device configuration, warning and alarm, fault and maintenance records. They can also monitor gas concentration, check status and perform real time diagnostics.
New Infrared Combustible Gas Detector: The versatile IR400 is suitable for a wide range of hazardous industry processes and plant applications: LNG/LPG processing and storage, electric power generation plants, oil/gas production platforms, petrochemical refining, pipeline compressor stations, aerospace facilities, and wastewater treatment. The IR400 comes with the following industry approvals: FM, CSA, ATEX, CE Marking and IECEx. It is also certified as SIL 2 capable.
