Yokogawa releases GX and GP Series paperless recorders: the first components of the SMARTDAC+™ next-generation data acquisition and control system

Yokogawa Electric Corporation announces the release of two new product series, the GX panel-mounted paperless recorders and the GP portable paperless recorders. These are components of SMARTDAC+™, a newly developed next-generation data acquisition and control system with excellent operability and expandability.

Key features of the new recorders include a smart user interface, smart architecture and smart functionality.

The intuitive smart user interface is engineered for ease of use via two-point touch screen technology similar to that found in the latest tablets and smartphones. To read the digital values for a specific location on a waveform image, users only need to drag a scale to that position. And, with a “spreading” or “pinching” multi-touch gesture, users can zoom in or out on a waveform image. The resistive touch screen can even be operated while wearing gloves.

The new units feature a highly flexible and scalable smart architecture with expandable modular construction. By selecting the appropriate input/output modules, users can easily configure I/O segments for a specific measurement task. The GX20 and GP20, each of which comes with a large touch panel, can accommodate up to ten modules or 100 I/O channels; the GX10 and GP10, which have a smaller touch panel, can accommodate up to three modules or 30 channels.

Smart functionality includes advanced data-logging and communication functions. The high-capacity internal memory supports continuous recording of many input channels. The external memory slot accepts the use of SD memory cards of up to 32 Gbyte capacity, offering local backup facility of data files for months or years.

The GX and GP recorders support the Ethernet international LAN standard. In addition, FTP support enables all recorder data to be managed through a file server. A printer output function enables direct printing of reports and “snapshots” from the GX and GP recorders. These recorders also support Modbus communications.

Future products in the SMARTDAC+ system will include input modules for a variety of signal sources and output modules for control applications.
