Achieve ROI within Days Using Real-Time Color Analysers for Pipeline Measurements

Nov 15 2017 Comments 0

Given the large volumes of liquefied natural gas (LNG) under transport, ROI from using real-time measurement systems, such as Guided Wave’s Saybolt Color Analyser, can be measured in days! Prior to liquefaction, residual materials are removed with only clean hydrocarbons remaining. The composition of natural gas can vary slightly from different producing locations. Typically LNG is a colorless material, but during distillation the carryover of larger hydrocarbons (C6+) can affect the color of LNG. Many liquid product specifications are based on color measurements. Changes in color can be an indicator of final product quality as well as a means to control process variables when implemented in real time. There are different color “scales” that apply to different products or industries. Some common examples are Saybolt, ASTM, and APHA (aka Platinum-Cobalt, or Hazen). Measuring the Saybolt or ASTM color online is a key parameter in many light hydrocarbon mixes for quality control to detect the C6+ hydrocarbon carryover. Monitoring the color allows the refinery to verify that the product is within specification. Any “out-of-spec” product can be reprocessed before being sold.


Guided Wave’s NEW Saybolt Color Analyser is based on the adaptive ClearView® db platform. The ClearView db instrument can be programmed to measure many different parameters of many different samples, i.e., it can be adapted to customers’ current and future measurement needs without significant hardware changes and with few restrictions.

Since the ClearView db analyser can be configured for different color scale measurements, it is possible to have a two channel ClearView db analyser configured for two different color measurements such as ASTM (D1500, D1524) and Saybolt, accomplishing both measurements with one analyser simultaneously saving customers time and money.

The Saybolt Color Analyser is calibrated for Saybolt and is a ready to-go solution for accurate, real-time, reliable fuel quality and control results.

The Smart Choice for Reliable Color Measurement

Guided Wave color analysers are built on the proven multi-wavelength ClearView db technology. This filter photometer is a dual beam design that provides increased stability and higher accuracy over other single beam photometers. The complete “ready-to-go” analytical systems from Guided Wave include:

1) Analyser (photometer)

2) Fiber optic cables

3) Sample interface (probe or flow cell)

4) Control software and pre-calibration to the specific color application.

LEARN MORE click here to get any of the information below

Get Application Note and Product Data Sheets:

  • LNG application note
  • Saybolt product data sheet
  • ClearView db product data sheet


Request White Paper:
Find out how another Guided Wave customer increased their profitability

  • “Novel Configuration for NIR Analysis of LPG Composition and Quality Control in a Refinery Setting”


Attend Webinars:
Learn how an international company increased their profitability in pipeline purity management by using an NIR spectrometer instead of a GC

  • WEBINAR TITLE: A Novel Configuration for NIR Analysis of LPG Composition & Quality Control

Learn how to both qualitatively and quantitatively detect changes of products going down the pipeline to minimize switching times, while maximizing useful products to be stored and sold.

  • WEBINAR TITLE: Product Pipeline Interface Detection
