Emerson Announces High Density Pneumatic Valve Island, Enabling Reduced Installation Costs

Jan 17 2018 Read 1019 Times

Emerson announces a major update to the ASCO Numatics G3 Series electronic valve island platform, enabling a reduction in installation costs. The valve island has been expanded so that it can control up to 128 solenoid valves on a single valve island assembly. This allows more valves to be controlled from a single node, enabling savings in the number of nodes and the cabling, internal tubing and electrical connections in the cabinet. Customers will benefit when they control a high density of valves or pneumatic equipment in a packaging plant or on a skid. 'The new functionality enables designers to minimise expensive cabinet space and have fewer nodes dedicated to pneumatic valve islands,' said Uwe Claus, Global Vice President Marketing. Now, designers can place more valves in a single cabinet or use a smaller enclosure to house the same number of valves. In addition, installers will only have to set up and configure one node, saving time and labour cost.

The expanded valve platforms can support up to 128 11mm solenoid valves and up to 80 18mm and 26mm valves. To increase the valve platforms´ capacity, mid-station blocks were added with valve drivers and auxiliary power connectors. This flexible approach allows customers to pay only for the capacity and functionality required in their design. A wide variety of communication protocols are supported, including Ethernet/IPTM DLR, Profibus® DP, and Valve Sub-bus for distribution.

It is highly recommended that customers use the flexible and powerful online Dynamic Product Modelling (DPM) tool when designing pneumatic valve island installations to save time in design and selection. The DPM tool enables the valve islands to be fully configured. It produces a unique specification for that product and enables a CAD drawing to be downloaded.

'Our new G3 Series platform is ideal for use in life science (pharmaceutical and biopharmaceutical), food and beverage, fine chemicals, and water/wastewater applications' Claus said.

For further information please click here.
