  • SIL-2 Compliant Level Switch Supports Storage Tank Monitoring Applications

SIL-2 Compliant Level Switch Supports Storage Tank Monitoring Applications

Aug 09 2009 Read 1332 Times

Process and plant engineers responsible for monitoring storage tanks required for critical operations or those located in hazardous environments will find the FLT93 Tank Level Switch from US manufacturer Fluid Components International (FCI) is now rated for Safety Integrity Level (SIL) 2 compliant service.

FCI’s SIL-2 compliance rating for the FLT93 Tank Level Switch has been documented in a failure analysis report with FMEDA techniques by the testing laboratory TUV Nord Cert GmbH. The FLT93 Tank Level Switch has been classified as a Type A subsystem in accordance to IEC 61508-1 with a hardware failure tolerance of 0. The Probability of Failure on Demand (PFD) meets SIL-2 capability standards.

FCI’s FLT93 Tank Level Switch has an unmatched industry record of superior performance and reliability in rugged industries that include chemical processing, oil/gas refining, nuclear power and more. Depending on the model chosen, the FLT93 measures tank level or interface up to ±0.1 inch (±2.5 mm) accuracy with a repeatability of ±0.05 inch (±1.3 mm). It operates within temperatures from - 100ºF to 500ºF (-73ºC to 260ºC) and has been hydrostatically proof pressure tested to 3500 psig [240 bar (g)].

A wide selection of standard and custom process connections can be provided. The electronic control circuit can be integrally-mounted with the sensing element, or it can be located in a remote location. The standard enclosure is made from a coated aluminum alloy. It is suitable for use in hazardous (FM, CSA, and ATEX classified) locations and is rated for NEMA Type 4X (IP66) environments. The FLT93 Tank Level Switch comes with a three-year warranty.

For process and plant engineers in all industries, safety considerations for people and facilities are a crucial factor when specifying process technologies. SIL ratings provide a key assurance of confidence that the safety rated equipment has been tested and shown to prevent dangerous failures and to control them in the event they occur. FCI’s new SIL-2 safety compliance assures its customers that the third-party testing organization (TUV NORD) has tested the FLT93 Tank Level Switch and when the product is in use, the process risk is reduced to the designated level. FCI’s customers can rely on the company to continually improve the safety and reliability of all of its solutions.

The versatile FLT93 Switch Series features a unique FlexSwitch® design that can also monitor flow and temperature. The advanced FLT Switch reliably monitors the flow, level and
interface of liquids, gases, slurries, syrups, lubricants, coolants and more.
