Plastic Seal Gauge for Isolated Pressure Sensing System

Reotemp’s (USA) Series PLG combines a plastic diaphragm seal with an industrial pressure gauge, creating an isolated pressure sensing solution. This unit comes from the factory mounted, filled, and ready for installation. The plastic diaphragm seal is ideally suited for chlorine service and other corrosive environments.

Applications include: wastewater treatment, seawater, chemical plants, the plating industry, and the fertilizer industry. The diaphragm seal housing is available in PVC, Polyproplene, or Kynar. The diaphragm is made of Teflon. This unit has a working temperature range of -22°F to 248°F. The PLG can be filled with silicone (standard), glycerin, or mineral oil. Available pressure ranges include 0 to 15 PSI up to 0 to 150 PSI.
