Process Trace Moisture Analyzer for Hydrogen Metering and Gas Grid Infeed Plants

Oct 28 2020 Read 651 Times

Author: Josef Kraus on behalf of Bartec Benke GmbH

Free to read

Articles are free to download. Unlock the article to be shown more content, graphs and images.

Unlock

The conversion of electric power from renewable sources to Hydrogen is another key technology to decarbonization and seasonal energy storage.



Reliable moisture measurement to comply contracted limitsand ensure safety

Polymer Electrolyte Water Electrolysis (PEM) or Alkaline Water  Electrolysis areenhanced principles fordecomposing Water to Hydrogen and Oxygen by use of electric current. Electric power  from renewable sources like wind or solar  power is usually not  congruent to the actual demand of electricity. The conversion of electric power to Hydrogen makes is storable and capable to be  transported at the existing gas pipeline grid, where it can be re-electrifiedwhen required or used as fuel for cars or other industrial processes. Nowadays the common low-temperature principles are PEM and Alkaline type electrolysis unitswhere the interchange of atoms and ions by removal or addition of electrons  from  external  power  source  takes place.  Usually  several  cells  are  combined  to stacks for the production of very pure and dry Hydrogen which is also already pressurized. At the gas pressure regulating and  metering station the Hydrogen is analyzed on traces of Oxygenand Nitrogen, flow rate and heating value. The analysis of trace humidity is of particular importance when additional  gas compression is needed to feed the gas to the natural gas  pipeline  grid. Contracted feed-in limits (e.g. 50 mg/m³ Moisture) are important to prevent condensation in pipeline which lead to operational problems (corrosion and erosion) and safety risk (water slugs and even blockage by hydrate formation).
A suitable moisture analyzer for this application is  hallmarked  byitsreliability,especially  in cases where  the  plant  is  operating  to  load-follow thedemand of Hydrogen. The BARTEC Benke’s trace moisture sensors are trimmed to superior robustness andeven (unwanted and unexpected) water slugs does not damage the sensor. On request the reliability of the sensor calibration is assured and tested by an independent and accredited laboratory on request.
Most of the plants are small sized and unmanned or are even locatedat  offshore  platforms. A regular sensor exchange or extensive maintenance must be avoided to keep the operational cost as low as possible. And in case of yearly check, the installation of the sensor with a sensor retraction armature makes maintenance easy, quick and without process interruption.



The HYGROPHIL F is designed for the needs of the natural gas industry

The core element of the moisture sensor is an optical thin film element made of silicon dioxide and zirconium dioxide. The microporous stack of alternating high and low refracting  optical layers is forming a Fabry-Pérot Interferometer with a distinctive and reliably detectable reflection minimum in the spectral range around 820 nm. Selective to water, molecules  can diffuse into the porous Fabry-Pérot  element, which then performs a shift of the reflection minimum in proportion to the actual water vapour pressure. The spectral shift is detected and evaluated with a compact high-resolution polychromator, which is located in the evaluation unit together with the light emitting diode. The interconnecting fiberoptic cable can be up to 800 m long  because of the detection of an optical minimum instead of an   intensity change. The evaluation unit processes and calculates the present  dew point temperature as well as other units such  aswater  vapour pressure, parts per million, mg/m³  and further  more. It offers the indication of the dew point temperature at current line pressure as well as to different defined reference pressure. Optionally the calculation from dew point temperature to mg/m³ can be done in conformity to DIN EN ISO 18453, which takes respectof the entered gas composition.
Several analog outputs, MODBUS, PROFIBUS  RTU and via  TCP/IP as well as relay contacts are equipped as standard for interconnection to the control system.



Thousands of installations worldwide   prove the advantages of this measurement principle:

• Robust sensor construction for outstanding long-term stability (ideal for offshore applications)
• Sensor validation in Hydrogen by accredited and independent laboratory available
• Easy sensor cleaning and almost no maintenance required
• In-line installation with sensor retraction armature possible (fast response and emission-free)
• Flexible on-line solutions with customized sample conditioning systems
• Certified for safe operation in hazardous area (ATEX, IECEx, CSA, TR CU)
