State of the art of CO2-recycled fuels : a new frontier for alternative energy technologies

May 20 2022

Author: Dr. Raj Shah, Nikhil Pai and Nathan Aragon on behalf of Koehler Instrument Company

Free to read

Articles are free to download. Unlock the article to be shown more content, graphs and images.

The majority of transportation methods, such as aircraft, sea vessels, and land vehicles, are entirely reliant on hydrocarbon fuels for energy. Typically, these hydrocarbon fuels are produced from limited feedstocks, including coal, natural gas, crude oil, and biomass. As such, there is substantial interest in alternative and more sustainable energy sources. Though there exists a general trend towards electric propulsion, it requires an overhaul of all existing vehicle powertrains and significant upgrades to the electrical grid.  As such liquid hydrocarbon fuels will be required well into the future. Also, it is important to consider the impact of CO2 as a greenhouse gas. With the United States recently entering the Paris Climate Accords, interest in CO2 reduction has been revived. With such widespread interest in both hydrocarbon fuels and carbon dioxide reduction, CO2-based e-fuels present an attractive solution to both problems.

Essentially, through the use of renewable or nuclear power, CO2 and water can be converted to hydrocarbon fuels. The conversion process consists of 4 main stages as shown in Figure 1. The first process; first is the collection of energy. With the environmental impact of energy collection in mind, sources would ideally consist of wind farms, solar farms, or nuclear sources. Next is the collection of H2O and CO2 for conversion. In the case of these electrofuels (e-fuels), sustainability is primarily dependent on the availability of carbon capture and storage technologies, as well as the efficiency of the conversion process. The sustainability of synthetic hydrocarbon fuels is largely dependent on the source of the feedstock. Due to the nature of CO2 and H2O as feedstock, the process is scalable. In initial, localized projects, CO2 could be captured from industrial sources, such as factories. As projects expand and multiply, the ideal scenario entails carbon capture directly from the atmosphere [1]. Just as CO2 is fairly abundant, the sourcing of H2O in large quantities is fairly straightforward, with seawater readily available.
Third, the oxides must be dissociated to create syngas, a mixture of CO2 and H2O. Finally, the syngas must be synthesized into usable fuel. For each step exists various technological avenues which must be examined to develop a streamlined and efficient process. The current state of the technology indicates that the high-temperature electrolysis of H2O and CO2 in a solid oxide cell, resulting in CO and H2, coupled with catalytic fuel synthesis, is a promising route. This paper seeks to summarize and reflect on the existing state of the art, as well as recommend avenues for further research and optimization.



Collection

After the collection of energy, ideally from renewable sources, the raw feedstock must be amassed. For the purposes of collection, CO2 can be classified into two categories:; atmospheric and non-atmospheric. Historically, non-atmospheric CO2 has been successfully captured from industrial plants [3]. Another non-atmospheric source of CO2 that should be considered is geothermal vents and their respective power plants. Some research exists regarding the collection of CO2 from Icelandic vents [3]. When considering large-scale projects, however, the collection of atmospheric CO2 should be prioritized.
The extraction of atmospheric CO2 from the air dates back to the 1940s when an alkaline absorbent was first used to obtain CO2 from the air. The use of alkaline absorbents is by far the most popular method of CO2 collection. Typically, metal hydroxides, including KOH and NaOH are used to react with CO2 to form carbonates, typically in the form of solutions [4-8].
The chemical reaction in these collections is: CO2 + 2OH- → CO32- + H2O

Once the CO2 is absorbed, the absorbent must be regenerated with electrical or thermal energy.
Also used are carbonate solutions, which absorb CO2 and form bicarbonates [9-13].
With carbonate collection, the reaction proceeds as follows: CO2 + CO32- + H2O → 2HCO3-
The benefit of carbonate collection is that the CO2 forms weaker bonds with the carbonate than with a hydroxide. This translates to less energy being needed to release the CO2 and regenerate the absorbent for future use. However, this also means that absorption into the carbonate would require either increased contact with the air or more absorbent. A study examining the energy requirements for various methods of air capture showed that a dilute carbonate solution required the least amount of energy. Practically, however, the absorption rates of a carbonate solution could be too slow to be used in a large-scale project.
Naturally formed mineral carbonates have also successfully been used to capture CO2 from the air. Nikulshina et al. studied the use of CaO and Ca(OH)2 particles in carbon capture [14]. The particles were carbonated at 350-450 degrees Celsius, resulting in CaCO3, which was then calcined at 800-875 degrees CelciusCelsius to release CO2. Also, to be considered arethe methods of CO2 absorption optimization ought to be considered. One particularly interesting area of the technology involves the geometry of the air contactor. Packed beds [15] and spray towers [16] are promising methods of air contact.
After being captured in a medium, the  capturing the CO2, the carbon dioxide must be released from the capture medium, and the capture medium must be prepped for reuse. In the case of alkaline solutions, this process can be electrically driven through electrodialysis [17-20] or thermally driven in the case of calcifying carbonates [6, 15, 18, 21-24]. Also to be consideredConsiderations must be made for the in the  electrolysis of the spent absorbent as well. This process would integrate the regeneration of the absorbent with the dissociation stages of H2 and O2. As most practical CO2-derived fuel processes involve the production of H2, the production of H2 and O2 along with the release of CO2 provide a unique opportunity for energy efficiency. The main disadvantage to this method is that O2 and CO2 are released into the same compartment of the electrolysis stage. Separating the two would require another step of gas-phase separation. Alternatively, the use of a three-compartment cell with separate releases of carbon dioxide and dioxygen has been proposed, which would eliminate the need for a separation stage [25-27].
For large-scale e-fuel projects, ideal water sources would be seawater. While this would add the step of desalination to the process, the fiscal impact would be minimal. With the addition of desalination, the end cost of one gallon of synthetic gasoline would only increase by less than a cent.



Dissociation

The next stage in the process is the dissociation of H2O and CO2. This stage of the process can be approached in several ways. Electrical energy and electrolysis can be used to power the dissociation. When considering the general cost of energy, however, the use of thermal energy may be advantageous over electricity. The dissociation of H2O into H2 has been the subject of far more research than CO2 dissociation. Once obtained, it is possible to use hydrogen to reduce the CO2 to CO through the reverse water-gas shift reaction: H2 + CO2 ⇄ H2O + CO
Alternatively, CO can be used to reduce H2O to H2 in the water-gas shift reaction, the reverse of the above.
An alternative to electrolysis is thermolysis, which uses thermal heat to form syngas. Overall, thermolysis is a theoretically optimal method for H2O and CO2 dissociation. Full thermolysis occurs at temperatures exceeding 3000-4000 degrees Celsius. For H2O alone, however, a temperature range of around 2000-2500 degrees Celsius is acceptable [28-30]. While the combustion of fuel in a chlorine or oxygen atmosphere could be used to reach the desired temperatures, this would be counterintuitive, as more fuel would be used than produced. Therefore, electric and solar furnaces should be used to provide the high temperatures needed for thermolysis.
Jensen et al. developed a thermolysis chamber for CO2 utilizing concentrated sunlight. The observed peak energy conversion was around 5%, with projections of a 20% yield in the future [31-32]. Though the conversion value is low, the process also produced unused heat, which could be converted into electrical energy to boost efficiency. If a 20% yield is obtained and the unused heat is utilized, the overall efficiency of the process would be roughly 50%. However, the thermolysis process is more expensive to keep stable, requiring materials that remain stable at elevated temperatures and multiple steps of heat management. This may outweigh the advantages of high efficiency. Another concern is the stability of materials within the chamber. The chamber reaches upto upwards of 2400 degrees Celsius with direct sunlight. However, due to rapid changes in the solar accessibility from clouds and other obstructions, thermal shock is a concern. Though this subset of dissociation shows promise, the expenses and requirements are so elevated that the development of a financially practical process is unlikely.
Dissociation can also be achieved via thermochemical cycles through a series of thermally driven reactions. The primary advantages of thermochemical cycles as a method of dissociation is are that product separation is inherent in the process and the process is carried out at lower temperatures than thermolysis. Typically, two-step cycles are  used. First, the metal oxide is reduced, resulting in the O2, and then oxidizing the metal by reaction with H2O or CO2, producing H2 or CO:
MxOy + heat → MxOy-1 + 1/2 O2 (g)
MxOy-1 + H2O → MxOy + H2 (g)
Typically, these cycles are driven by concentrated sunlight [29, 30, 33] or nuclear reactor heat. The first step in the two-step cycle typically requires temperatures as high as 2000 degrees Celsius. With high-temperature dissociation comes the same pitfalls as with the thermolysis processes,; namely material stability and thermal management expenses. Some two-step cycles aim to overcome these setbacks and achieve lower reaction temperatures. Some promising research exists regarding the use of modified ferrites with Co, Ni, or Mn substitution, as well as the use of ceria materials as the oxidation-reduction media.. These methods have been successfully used to dissociate H2O [34-41] as well as CO2 [34, 40, 42] to yield syngas. The reduction temperatures for cycles using these materials are sub-1500 degrees Celsius. Furthermore, ceria-based materials as a redox medium show promise, with stable performance after hundreds of cycles [40].
While these cycles are the most researched, hundreds of other possible cycles have been identified with various operating temperatures [43]. Realistic efficiencies for net solar-to-chemical energy conversion are estimated to be 16-25%. While the use of thermal cycles remains promising, until the margins of efficiency can be improved, it is not suitable for wide -scale e-fuel production.
Electrolysis is the simplest of all dissociation methods. An electrolysis cell dissociates the molecules using electrical energy in a single step. The products are released separately, eliminating the need for gas-phase separation. Also of note is the ease of integration with renewable energy sources. The addition of a photovoltaic cell for power is far easier and more scalable than the use of solar furnaces. Typically, solar furnaces would require mechanical sun tracking to concentrate the sunlight to reach high temperatures. With an electrolysis cell and PV cell, such a system would be unnecessary, making the method ideal for mass production [2].



Fuel Synthesis

Once the dissociation process is finished, the energy-rich components can be catalyzed into syngas. The obvious method by which the fuel should be synthesized is Fischer-Tropsch synthesis (FTS). FTS was developed in the early 20th century and has been successfully used in coal-to-liquid projects [44].
The reaction is as follows: 2H2(g) + CO(g) → _CH2_(l) + H2O(g) + 165 kJ(at 400 K)
Depending on the catalysts used, syngas composition, and temperature and pressure conditions, various hydrocarbons can be produced. Temperatures around 300-350 degrees Celsius yield gasoline, while lower temperatures around 200-240 degrees Celsius yield diesel. Methanol can also be produced via a similar process. Methanol synthesis is typically performed by reforming syngas over a Cu-ZnO/Al2O3 catalyst.
The reaction is as follows:  CO(g) + 2H2(g) → CH3OH(l) + H2O(g) + 128 kJ(at 298 K)
High methanol selectivity is achieved in high pressure, low-temperature conditions. A similar reaction can achieve methanol synthesis from CO2 and H2 [45]:
CO2(g) + 3H2(g) → CH3OH(l) + H2O(g) + 87 kJ(at 298 K)
This process has been carried out with a methanol synthesis reactor at temperatures around 200-300 degrees Celsius and pressures ranging from 50-100 bar [18].
Overall, FTS is by far the most studied and tested method of fuel synthesis and should therefore be considered the prime avenue for large-scale synthesis projects.



Challenges with E-fuels

The largest challenge with e-fuels is the amount of energy required for the overall process.  Figure 2 displays the amount of energy required for three different options.  The first alternative uses e-fuel, which requires 1 MJ of energy to provide 150 kJ of locomotion.  The second alternative simply uses the electricity directly for propulsion, resulting in 900 kJ of the original 1 MJ going towards locomotion.  The third option uses a hydrogen fuel cell, where 420 kJ of the original 1 MJ goes towards locomotion.  As such, there is a significant amount of wasted energy in the process.  In an ideal world, this would not be an issue since the energy is being sourced from renewable sources (i.e., they all have the same zero carbon footprint).  However, there would be competing markets for the same energy and wasted energy would equate to lost revenue.
The overall benefit of e-fuels is that they do not require an overhaul of the vehicle fleets.  Most vehicles could readily swap out diesel or gasoline for the appropriately produced e-fuel.  As such, it is a good stop-gap measure to reduce the dependency on fossil-based fuels and reducing the carbon footprint of the transportation industry.  However, unless the production efficiency can be substantially increased through the aforementioned advancements, e-fuels will simply not be feasible.
 Figure 2: Comparison of three different pathways to provide locomotion



Conclusion

In the past 50 years, the use of fossil fuels as a chemical energy source has continued to grow. Though nuclear and renewable energy sources display remarkable potential, the transportation sector is arguably more receptive to the continued use of hydrocarbons over carbon-free energy carriers. Liquid hydrocarbon fuels have a higher energy density than alternatives, as well as an existing infrastructure in vehicles and distribution. As such, the sustainable sourcing of hydrocarbons from renewable resources is an extremely desirable goal.
Carbon dioxide and water are the most obvious feedstock, as they are both readily available. The first task is collection. The ideal method of collection for CO2 is through the use of hydroxides or carbonates to scrub the air and form carbonates and bicarbonates, respectively. Initial implementation of carbon-capturing should be focused on capture from industrial plants or geothermal vents. As carbon capture technology develops and becomes more efficient, the collection of CO2 can become a location-independent process. For water, desalinated seawater is a practical and economical source.
Once the feedstock is amassed, the molecules must go through a dissociation process. This process is the most energy-intensive portion of the e-fuel process. As the overall goal of such a project is to reduce the dependence on fossil fuels and source energy sustainably, the energy for the dissociation should be sourced from renewable or nuclear options. Thermochemical cycles are a promising method of dissociation. However, the high-temperature nature of the reaction presents several challenges, including thermally stable material sourcing and heat management. While solar furnaces have been used to reach the desired high temperatures, due to the intermittent availability of direct sunlight and the need for sun-tracking technology, solar energy would be better harnessed through PV cells. These solar receptors could be attached to an electrolysis cell, which would be used to dissociate CO2 and H2O into CO and H2, respectively.
 As the building blocks for all hydrocarbon fuels, the syngas components can be synthesized, with the help of a catalyst, through the Fischer-Tropsch synthesis reaction. This reaction has been successfully used to achieve liquid hydrocarbons. Additionally, methanol synthesis reactors have been used to produce gasoline and diesel products.
Currently, the dissociation stage of the process is the weakest link. With the highest energy requirements and low efficiency, the processes and equipment need further optimization for e-fuel synthesis to become widely used. As sufficient literature is published on the optimization of the dissociation process and the efficiency is improved, the use of synthesis techniques to recycle H2O and CO2 will become sustainable and widely adopted.


References

[1] Lackner KS. Capture of carbon dioxide from ambient air. The European Physical Journal – Special Topics 2009;176(1):93–106.
[2] Graves, C., Ebbesen, S.D., Mogensen, M. and Lackner, K.S. (2011). Sustainable hydrocarbon fuels by recycling CO 2 and H 2 O with renewable or nuclear energy. Renewable and Sustainable Energy Reviews, 15(1), pp.1–23.
[3] Thambimuthu KK, Soltanieh M, Abanades JC, Allam R, Bolland O, Davison J, et al. Capture of CO2, in IPCC special report on carbon dioxide capture and storage. In: Abu-Ghararah Z, Yashima T, editors. Intergovernmental panel on climate change. Working Group III; 2005. p. 105–78.
[4] Steinberg M. Electrolytic synthesis of methanol from CO2. USPTO 3,959,094; 1976
[5] Steinberg M. Synthetic carbonaceous fuels and feedstocks from oxides of carbon and nuclear-power. Fuel 1978;57(8):460–8.
[6] Lewis JG, Martin AJ. Method for obtaining carbon dioxide from the atmosphere and for production of fuels. USPTO 4,140,642; 1979.
[7] Corbett MJ, Salina SC. Production of synthetic hydrocarbons from air, water and low cost electrical power. USPTO 4,282,187; 1981.
[8] Corbett MJ. Synfuel production ship.USPTO 4,568,522; 1986
[9] Steinberg M. Production of synthetic methanol fom air and water using controlled thermonuclear reactor power—I. Technology and energy requirement. Energy Conversion 1977;17:97–112.
[10] Dang VD, Steinberg M. Production of synthetic methanol from air and water using controlled thermonuclear reactor power—II. Capital investment and production costs. Energy Conversion 1977;17(4):133–40.
[11] Martin FJ, Kubic WL. Green FreedomTM: a concept for producing carbonneutral synthetic fuels and chemicals. Los Alamos National Laboratory; 2007 [LA-UR-07-7897].
[12] Phillips, Isenberg AO. Hydrocarbon production from inorganic carbonate minerals – and water, with process heat supplied by nuclear reactor. SPTO 4428-905-A; 1984.
[13] Georgievskii SS, Koval AI, Tumanovskii AA, Ulybin VB. Mathematical model of carbon dioxide synthesis by electrothermal decomposition of sodium bicarbonate. Chemical Physics Reports 1998;17(9):1733–8.

[14] Nikulshina V, Ayesa N, Ga´lvez ME, Steinfeld A. Feasibility of Na-based thermochemical cycles for the capture of CO2 from air—thermodynamic and thermogravimetric analyses. Chemical Engineering Journal 2008; 140(1–3):62–70.
[15] Zeman F. Energy and material balance of CO2 capture from ambient air. Environmental Science and Technology 2007;41(21):7558–63.
[16] Stolaroff JK, Keith DW, Lowry GV. Carbon dioxide capture from atmospheric air using sodium hydroxide spray. Environmental Science & Technology 2008;42(8):2728–35.
[17] Bandi A, Specht M, Weimer T, Schaber K. CO2 recycling for hydrogen storage and transportation—electrochemical CO2 removal and fixation. Energy Conversion and Management 1995;36(6–9):899–902.
[18] Weimer T, Schaber K, Specht M, Bandi A. Methanol from atmospheric carbon dioxide: a liquid zero emission fuel for the future. Energy Conversion and Management 1996;37(6–8):1351–6.
[19] Giner J. Carbon dioxide absorber means and fuel cell to regenerate absorbent. USPTO 3,519,488; 1970.
[20] Prigent M, Dezael C. Process for removing carbon dioxide from gases. USPTO 3,692,649; 1972.
[21] Weimer T, Specht M, Bandi A, Schaber K, Maier CU. CO2 removal and fixation solar high temperature syngas generation for fuel synthesis. Energy Conversion and Management 1997;38(Suppl. 1):S379–84.
[22] Lackner KS, Ziock H-J, Grimes P. Carbon dioxide extraction from air: is it an option?In: Proceedings of the 24th international technical conference on coal utilization & fuel systems; 1999. p. 885–96
[23] Zeman FS, Lackner KS. Capturing carbon dioxide directly from the atmosphere. World Resource Review 2004;16(2):157–72.
[24] Keith DW, Ha-Duong M, Stolaroff J. Climate strategy with CO2 capture from the air. Climatic Change 2006;74:17–45.
[25] Steinberg M. Synthetic carbonaceous fuels and feedstocks from oxides of carbon and nuclear-power. Fuel 1978;57(8):460–8.
[26] Steinberg M. Synthetic carbonaceous fuels and feedstocks. USPTO 4,197,421; 1980.
[27] Hartvigsen J, Joshi AV, Elangovan S, Balagopal S, Gordon JH, Hollist M. Electrochemical cell for the production of synthesis gas using atmospheric air and water. WIPO WO/2007/025280; 2007.
[28] Kogan A, Spiegler E, Wolfshtein M. Direct solar thermal splitting of water and on-site separation of the products. III. Improvement of reactor efficiency by steam entrainment. International Journal of Hydrogen Energy 2000;25(8): 739–45.
[29] Perkins C, Weimer AW. Likely near-term solar-thermal water splitting technologies. International Journal of Hydrogen Energy 2004;29(15):1587–99.
[30] Steinfeld A. Solar thermochemical production of hydrogen—a review. Solar Energy 2005;78(5):603–15.
[31] Jensen RJ, Lyman JL, King JD, Guettler RD. Solar reduction of CO2. USPTO 6,066,187; 2000.
[32] Traynor AJ, Jensen RJ. Direct solar reduction of CO2 to fuel: first prototype results. Industrial & Engineering Chemistry Research 2002;41(8):1935–9.
[33] Kodama T, Gokon N. Thermochemical cycles for high-temperature solar hydrogen production. Chemical Reviews 2007;107(10):4048–77.
[34] Miller J, Allendorf M, Diver R, Evans L, Siegel N, Stuecker J. Metal oxide composites and structures for ultra-high temperature solar thermochemical cycles. Journal of Materials Science 2008;43:4714–28.
[35] Abanades S, Flamant G. Thermochemical hydrogen production from a twostep solar-driven water-splitting cycle based on cerium oxides. Solar Energy 2006;80(12):1611–23.
[36] Kaneko H, Miura T, Fuse A, Ishihara H, Taku S, Fukuzumi H, et al. Rotary-type solar reactor for solar hydrogen production with two-step water splitting process. Energy & Fuels 2007;21(4):2287–93.
[37] Kaneko H, Ishihara H, Taku S, Naganuma Y, Hasegawa N, Tamaura Y. Cerium ion redox system in CeO2–xFe2O3 solid solution at high temperatures (1273–1673 K) in the two-step water-splitting reaction for solar H2 generation. Journal of Materials Science 2008;43(9):3153–61.
[38] Diver RB, Miller JE, Allendorf MD, Siegel NP, Hogan RE. Solar thermochemical water-splitting ferrite-cycle heat engines. Journal of Solar Energy Engineering 2008;130(4):041001.8.
[39] Abanades S, Legal A, Cordier A, Peraudeau G, Flamant G, Julbe A. Investigation of reactive cerium-based oxides for H2 production by thermochemical twostep water-splitting. Journal of Materials Science 2010;45(15):4163–73.
[40] Chueh WC, Haile SM. A thermochemical study of ceria: exploiting an old material for new modes of energy conversion and CO2 mitigation. Philosophical Transactions of the Royal Society A Mathematical Physical and Engineering Sciences 2010;368(1923):3269–94.
[41] Kaneko H, Taku S, Naganuma Y, Ishihara T, Hasegawa N, Tamaura Y. Development of reactive ceramics for conversion of concentrated solar heat into solar hydrogen with two-step water-splitting reaction. Journal of Solar Energy Engineering 2010;132(2):021202–21204.
[42] Loutzenhiser PG, Galvez ME, Hischier I, Stamatiou A, Frei A, Steinfeld A. CO2 splitting via two-step solar thermochemical cycles with Zn/ZnO and FeO/Fe3O4 redox reactions ii: kinetic analysis. Energy & Fuels 2009;23:2832–9
[43] Abanades S, Charvin P, Flamant G, Neveu P. Screening of water-splitting thermochemical cycles potentially attractive for hydrogen production by concentrated solar energy. Energy 2006;31(14):2805–22.
[44] Dry ME. The Fischer–Tropsch process: 1950–2000. Catalysis Today 2002;71:227–41.
[45] Mignard D, Pritchard C. Processes for the synthesis of liquid fuels from CO2 and marine energy. Chemical Engineering Research and Design 2006;84(9A):828–36.
