Introduction:

Wind power has been present for almost as long as humanity has existed. As early as 5000 BC, ancient Egyptians harnessed the winds to propel their vessels across the Nile1. The concept of wind power is so timeless and prevalent that it requires almost no introduction. However, it can still improve. As time progressed, wind power became much more than a propulsion mechanism. In the Eastern hemisphere, incarnations of wind power saw use in food production1, irrigation control1, and saw mills1, typically encapsulated in the familiar windmill shape as shown in Figure 1. And in the advent of electricity, it was only a matter of time before the wind would adapt for use in the electrical age. This adaptation manifested as wind turbines, which function like the windmills of the previous era by repurposing the wind to push blades and power an attached generator2.

Wind turbines come in all shapes and sizes2 for all purposes, but they are far from the only form of power. While one of the oldest sources of power, it has been completely eclipsed by fossil fuels in prominence and ubiquity. The efficacy of fossil fuels, however, was tempered by the deadly carbon emissions from their use. Recently, global organizations have lobbied in favor of curbing carbon emissions and pursuing cleaner energy alternatives in favor of reducing the effects of global warming and preserving the planet for future generations. Thus, wind power was once again at the forefront, and in recent years, that attention has resulted in numerous groundbreaking innovations in the field of wind power. This article catalogs several innovations in wind power across the past 3-4 years, noting the area of wind power it influences and its positive implications for future studies.



Wind Turbine Blades:


As wind turbines are ubiquitous, many have sought to innovate on the traditional wind turbine design, as shown in Figure 2. As a general trend, these wind turbines have grown larger to better harness and withstand stronger wind currents at higher altitudes3. Consequently, wind turbines have become harder to manufacture and maintain, owing to the steeper production and transport costs of the parts4, which leads to the construction of a single commercial turbine costing upwards of $4 million5, far beyond the grasp of many prospective buyers. Furthermore, wind turbine blades have an average lifespan of 20-25 years6 before they must be replaced, further compounding maintenance fees. The steep costs of turbine construction, transportation, and maintenance left wind turbines relatively expensive compared to other energy sources.
To combat this issue, researchers at the U.S National Renewable Energy Laboratory (NREL) 2020 posted a study detailing the practicality and reliability of an alternative wind turbine blade that utilized a thermoplastic resin composite rather than the traditional thermoset composition7. Because of its use of thermoplastics, the turbine blades could be created on-site8, drastically reducing the cost of production and transportation in one fell swoop. Furthermore, the turbine blades were very malleable through heat and could be melted down into resin, further cheapening the repair process and allowing the blades to be recycled at the end of their lifespan.
Finally, in the testing process, the group revealed that the thermoplastic blades behaved similarly to the standard blades while exhibiting greater structural damping, meaning that the thermoplastic blades take a far shorter time to return to their original displacement. If thermoplastic blades were cleared for mass production, wind turbine blades could be roughly 5 percent cheaper to produce and maintain8 while performing more reliably due to the malleable and adaptable thermoplastic material. Thus, thermoplastic blades could dramatically increase the sustainability and cost-effectiveness of wind turbine blades.



Vertical Axis Wind Turbines:

Vertical Axis Wind Turbines (VAWTs) date back to the 9th century9, relying on aerodynamic drag over lift for their propulsion mechanisms. Their design has also carried to modern energy systems, though lack of long-term interest8 for VAWTs means that they will remain in the shadow of horizontal axis wind turbines. However, they still have strong merits. Due to their vertical design, they are much more compact than horizontal turbines and thus can be placed in much denser arrays that can produce up to 10 times more power per unit area than horizontal turbines10. Additionally, their design makes them more suited toward hurricane-force winds than their horizontal counterparts11. Thus, VAWTs are prime for wind turbine farms set offshore, and one company has taken note of that.
Swedish turbine company SeaTwirl is a company that exclusively produces offshore vertical wind turbines, benefitting from the stronger winds in the ocean and the turbine’s greater structural strength11. Specific to this company’s turbines is a buoy and keel structure attached to the turbine tower, which allows the turbine to turn with the winds and maintain its stability through them. Furthermore, as the company employs several mooring lines in each structure, SeaTwirl turbines can be anchored farther than the traditional depth of 50-60 meters11 that offshore turbines are generally limited to. Thus, clients can create wind farms in consistently turbulent areas where other offshore turbines can’t anchor.
In their desire to further optimize the energy gain of their farms, SeaTwirl commissioned a researcher from the University of Manchester to verify the energy generation of several different configurations of offshore wind farms through wake modelling12. Each layout consisted of five rows of five turbines per row, differing by the distance between the turbines. Additionally, three horizontal wind turbine farm layouts were directly compared to their vertical counterparts. Table 1 details the layouts of the farms, and the variations between the layouts are detailed below. As expected in the test, the three vertical wind turbine farms outperformed their opponents due to their increased wake recovery12. Additionally, the study found that more slender VAWTs generate more energy and recover faster, as thinner rotors would further reduce wake interactions and increase energy gain. Thus, if vertical axis wind farms became the norm for offshore wind farms, power generation would increase dramatically due to the increased competence of VAWTs and this unique mooring system. Furthermore, if further research is conducted in this field, slimmer VAWT rotors may become the norm for offshore wind farms, and offshore farm energy generation will increase furtherized.

Table 1: The layouts of each analyzed wind farm. Sx = Streamwise spacing between turbines, Sy = Spanwise spacing between turbines. Source: https://seatwirl.com/content/uploads/SeaTwirl-wind-farm-layout-design_v5_FINAL.pdf

Figure 3: Energy output in GWh estimated tob e produced from offshore wind turbines using HWATs or VWATs with various configurations. Source: https://seatwirl.com/content/uploads/SeaTwirl-wind-farm-layout-design_v5_FINAL.pdf



Bladeless Turbines:

In addition to the existing models, a new wind turbine design uses aerodynamic principles to generate electricity from wind flow. While traditional wind turbine blades are efficient, they are loud and large. Their obstructive size and constant noise pollution make them near impossible to construct within cities. This is where bladeless wind turbines come in. As the name implies, these turbines do not possess blades, and all models utilize certain aerodynamic principles to manipulate the wind and generate electricity13. Due to this, bladeless turbines are far more compact and much quieter, allowing construction in densely populated areas. In this vein, we will focus on Aeromine Technologies, a startup company that proposes a remarkably compact bladeless turbine design14. Intended for rooftops, the device uses two vertical airfoils that generate a field of low pressure between them as air flows through the foils. This pulls the air through a cylindrical tower past a turbine at the base, generating electricity.
In contrast to its bladed counterparts, this design is far simpler, with fewer moving parts allowing for simpler installation and maintenance14. On top of this, the company claims that one Aeromine device generates as much electrical energy as 16 solar panels while taking up a fraction of the space and can function at wind speeds as low as five mph14. However, while the device cannot power a single building alone, it is meant to be a part of a combination of distributed energy sources, functioning with a conjunction of solar and other energy sources to power the grid.
To determine the efficacy of this technology, several researchers at Texas Tech University conducted a study examining the performance of an Aeromine device under a series of wind streams ranging from 5 to 15 m/s15. A 0.5 m chord pair of Aeromine foils were used along with the university’s wind tunnel to simulate freestream velocities, and a choke was placed to simulate the device’s optimum conditions at the same load as a standard turbine generator. Then, the mechanical efficiency of the system was calculated by comparing the power generated and the maximum possible power of the system. Following the experiment, the Aeromine device’s peak measured efficiency was calculated to be around 18%. This equates to roughly ⅓ of the Betz limit, the theoretical maximum efficiency of a wind turbine measuring around 59.3% of the kinetic energy from wind16. Standard turbines are more efficient than the measured results, equating to around 35-45% efficiency16. However, despite almost being half as efficient as a standard turbine, the device is also drastically smaller, measuring around 1.22 meters compared to a standard turbine which can be hundreds of times larger3. At that size, many more Aeromine devices can be arranged in the same amount of space that a traditional turbine occupies, generating much more energy while producing far less noise. While more experiments can further optimize energy output, Aeromine has already released a commercial model. If these models catch on, rooftop bladeless turbines may become commonplace, contributing much more electricity to the grid without requiring much adaptation for the existing electric grid.


Offshore Multi-Turbine Platforms:

Norwegian company Wind Catching Systems has designed a unique offshore wind farm that aims to further reduce construction and maintenance costs for offshore farms17. Rather than a traditional offshore wind farm, typically a horizontal grid of individual turbines, the company has designed a single vertical grid-like frame consisting of 126 rotors to generate a combined 126 MW of power18. As a traditional wind turbine has an output of roughly 8-15 MW19, the company claims that just five of these structures could equal the power generated by 25 conventional offshore turbines while occupying a fraction of the space17.
This structure, nicknamed the Windcatcher18, is enormous, spanning over 300 meters in length and height. But for its size, the rotors are comparatively smaller than those of traditional offshore wind farms, measuring 15 meters long compared to the standard 115-meter-long blades20. The smaller blades are intentional, however, as smaller blades are lightweight, perform more rotations per minute, and harness faster winds. Additionally, by placing the rotors close to each other, the company anticipates that the turbulence created by one rotor can be harnessed by the surrounding rotors, thus optimizing the performance of all rotors in sequence20.
Finally, by using readily available rotors and merging numerous rotors onto a single platform, the company hopes to reduce the price of energy from offshore turbines20. Due to the incredibly steep cost associated with offshore farms, offshore energy is far more expensive than other alternative energy sources20. The construction of the Windcatcher is an attempt to remedy this, as it combines readily available materials and techniques into a single framework to simplify the cost of repairs. From this framework, the company reports that the Windcatchers will cost less to produce than individual offshore turbines while generating more electricity and possessing a longer lifespan20. While still in development, the structure has drawn the attention and support of Norway and its government. Enova, an investment company owned by the Ministry of Climate and the Environment, has recently awarded Wind Catching Systems a grant of $2.1 million towards the design, construction, and testing of a scaled-down version of the Windcatcher on the West Coast of Norway18. While the structure is quite bizarre, if the company produces a working model, the future of offshore wind farms may be permanently affected by the arrival of floating multi-turbine platforms.

Figure 5: An image of a floating Windcatcher (304.8 m) next to the Eiffel Tower (300 m) for scale. Source: https://windcatching.com/



Conclusion:

To conclude, the field of wind power is ever-prevalent and ever-growing, from innovations to the blades to offshore developments that promise to drive offshore electricity prices down to smaller bladeless turbines that assist in providing alternative electricity to cities everywhere while remaining silent but effective. Still, many more developments are underway to make wind turbines more reliable and efficient. In particular, while the technology is still quite finicky, the growth of wind turbine sensors promises to be a significant upcoming development, as the ability to sense defects and damages within turbines can revolutionize turbine maintenance21. Wind power will continue to be a very innovative field. Wind turbines will grow larger, electricity will get cheaper, and alternative energy will prevail at the end of the day.



Resources:

1.    U.S. Energy Information Administration. “Wind Explained: [The] History of Wind Power.” 2023. [Online]. Available: https://www.eia.gov/energyexplained/wind/history-of-wind-power.php
2.    U.S. Department of Energy. “How do Wind Turbines Work?” [Online]. Available: https://www.energy.gov/eere/wind/how-do-wind-turbines-work.
3.    U.S. Department of Energy. “Wind Turbines: the Bigger the Better.” 2022. [Online]. Available: https://www.energy.gov/eere/articles/wind-turbines-bigger-better
4.    Utility Dive. “Wind Turbine Blade Sizes and Transportation: a Guide.” 2022. [Online]. Available: https://www.utilitydive.com/spons/wind-turbine-blade-sizes-and-transport-a-guide/623444/
5.    Blewett, D. “Wind Turbine Cost: How Much? Are They Worth It in 2023?” 2023. [Online]. Available:  https://weatherguardwind.com/how-much-does-wind-turbine-cost-worth-it/
6.    National Grid. “Can Wind Turbine Blades be Recycled?” [Online]. Available: https://www.nationalgrid.com/stories/energy-explained/can-wind-turbine-blades-be-recycled
7.    Murray, Robynne E. et al. “Structural validation of a thermoplastic composite wind turbine blade with comparison to a thermoset composite blade.” Renewable Energy. Vol 164, 2021, pp. 1100 - 1107. ISSN 0960-1481. Doi: 10.1016/j.renene.2020.10.040. [Online]. Available: https://www.sciencedirect.com/science/article/abs/pii/S0960148120316062
8.    National Renewable Energy Laboratory (NREL). “Advanced Thermoplastic Resins for Manufacturing Wind Turbine Blades.” [Online]. Available: https://www.nrel.gov/manufacturing/comet-wind-blade-resin.html
9.    Möllerström, Erik. et al. “A Historical Review of Vertical Axis Wind Turbines Rated 100 kW and Above.” Renewable and Sustainable Energy Reviews. Vol 105, 2019, pp. 1-13. ISSN 1364-0321. Doi: 10.1016/j.rser.2018.12.022. [Online]. Available: https://www.sciencedirect.com/science/article/pii/S1364032118308153
10.    American Institute of Physics. “Breakthrough Research for Testing and Arranging Vertical Axis Wind Turbines.” 2017. [Online]. Available: https://phys.org/news/2017-02-breakthrough-vertical-axis-turbines.html
11.    Cowan, L. “A New Wind Turbine Design Promises Better Offshore Energy.” 2022. [Online]. Available: https://inhabitat.com/a-new-wind-turbine-design-promises-better-offshore-energy/
12.    Ouro, P. “SeaTwirl’s Wind Farm Layouts Analysis.” [Online]. Available: https://seatwirl.com/content/uploads/SeaTwirl-wind-farm-layout-design_v5_FINAL.pdf
13.    Newton, E. “How a Bladeless Wind Turbine Works.” 2023. [Online]. Available: https://www.nacleanenergy.com/wind/how-a-bladeless-wind-turbine-works
14.    Clements, K. “Aeromine: An Elegantly Simple Rooftop Wind Energy Solution.” 2022. [Online]. Available: https://eepower.com/market-insights/aeromine-an-elegantly-simple-rooftop-wind-energy-solution/
15.    Pol, S. et al. “Performance of AeroMINEs for Distributed Wind Energy.” 2019. [Online]. Available: https://www.osti.gov/servlets/purl/1640929
16.    Energy Education. “Betz Limit.” [Online]. Available: https://energyeducation.ca/encyclopedia/Betz_limit
17.    Wind Catching Systems. “Unleashing the Power of Offshore Wind.” [Online]. Available: https://windcatching.com/
18.    The Maritime Executive. “Norway Funds Testing for Floating Wind Concept Using Multiple Turbines.” 2022. [Online]. Available: https://maritime-executive.com/article/norway-funds-testing-for-floating-wind-concept-using-multiple-turbines
19.    U.S. Department of Energy. “Offshore Wind Market Report: 2022 Edition.” 2022. [Online]. Available: https://www.energy.gov/eere/wind/articles/offshore-wind-market-report-2022-edition
20.    Hahn, J. “Wind Catching Systems Designs Giant Floating Wind Farm With 117 Turbines.” 2021. [Online]. Available: https://www.dezeen.com/2021/08/26/wind-catching-systems-floating-offshore-farm/
21.    SkySpecs. “10 Wind Energy Trends to be Aware of in 2023.” 2023. [Online]. Available: https://skyspecs.com/blog/wind-energy-trends-2023/
